Bonfix Alu-press threaded elbow 90°, press x female thread, Kiwa, 20 mm x ¾"

Bonfix Alu-press threaded elbow 90°, press x female thread, Kiwa, 20 mm x ¾"

SKU:15148917

$12.65
$12.65
Sale Sold out
In stock
View full details

Specifications

Angle
90 °
Connection size
20 mm, ¾"
Connection type
female thread x press
Diameter
20 mm, ¾"
Eancode
8717845021184
Material
brass
O-ring
EPDM
Oring
EPDM
Quality mark
Kiwa, KOMO
Type
Alu press

Description

This Bonfix Alu press screw elbow 90° is suitable for water, heating, and cooling systems.

In addition to this screw elbow 90°, the Bonfix Alu-press range includes various items such as:
  • Multi layer pipes.
  • Tools.

Properties

This Bonfix Alu-press pipe is suitable for a maximum constant temperature between -20 °C and 90 °C and a maximum working pressure of 10 bar.

Material

  • Housing: brass.
  • Press sleeve: stainless steel 304.

Assembly

The Bonfix tool must be used for pressing the coupling. The couplings up to 32 mm are equipped with a colored ring and can be pressed using a hand tool. Thanks to the Leak Before Pressure feature, unpressed connections are immediately detected during a pressure test.

The installation is done in just a few steps:
  • Cut the pipe to the correct length with a pipe cutter and deburr the ends to prevent a noisy pipe.
  • Slide the pipe into the press fitting until it is visible in the inspection window.
  • Place the fitting with the pipe in the pressing jaws and start the pressing process.
