Bonfix Alu press transition elbow 90°, press x compression, Kiwa, 16 x 15 mm

Bonfix Alu press transition elbow 90°, press x compression, Kiwa, 16 x 15 mm

SKU:15148953

$18.32
$18.32
Sale Sold out
In stock
View full details

Specifications

Angle
90 °
Connection size
15 mm/16 mm
Connection type
press x spigot
Diameter
15 mm/16 mm
Eancode
8717845131623
Material
brass
O-ring
EPDM
Oring
EPDM
Pid owner seller id jarola master repository
Jarola
Pid value seller id jarola master repository
15148953
Quality mark
Kiwa, KOMO
Type
Alu press

Description

This Bonfix Alu press transition elbow 90° is suitable for water, heating, and cooling systems.

In addition to this transition elbow 90°, the Bonfix Alu-press range includes various items such as:
  • Multi layer pipes.
  • Tools.

Properties

This Bonfix Alu-press pipe is suitable for a maximum constant temperature between -20 °C and 90 °C and a maximum working pressure of 10 bar.

Material

  • Housing: brass.
  • Press sleeve: stainless steel 304.

Assembly

The Bonfix tool must be used for pressing the coupling. The couplings up to 32 mm are equipped with a colored ring and can be pressed using a hand tool. Thanks to the Leak Before Pressure feature, unpressed connections are immediately detected during a pressure test.

The installation is done in just a few steps:
  • Cut the pipe to the correct length with a pipe cutter and deburr the ends to prevent a noisy pipe.
  • Slide the pipe into the press fitting until it is visible in the inspection window.
  • Place the fitting with the pipe in the pressing jaws and start the pressing process.

Want to buy the Bonfix Alu press system or need more information?

The desired press coupling can be ordered easily and quickly via our website or purchased in one of our branches. Are you not yet sure what the optimal coupling is for your situation? Contact one of our specialists for non-binding advice.
