Irritec Multibar C drip hose, 16 mm, drippers 1.6 l/h per 50 cm, l = 100 m

Irritec Multibar C drip hose, 16 mm, drippers 1.6 l/h per 50 cm, l = 100 m

SKU:15441405

$99.26
$99.26
Sale Sold out
In stock
View full details

Specifications

Capacity per dripper
1.6 l/uur
Connection size
16 mm
Drip element distance
50 cm
Eancode
8033278129953
External diameter
16 mm
Internal diameter
13.6 mm
Length
100 m
Maximum pressure
4 bar
Minimum pressure
0.5 bar
Pid owner seller id jarola master repository
Jarola
Pid value seller id jarola master repository
15441405
Strand length max. at 1 bar
113 m
Strand length max. at 2 bar
168 m
Strand length max. at 3 bar
202 m
Strand length max. at 4 bar
228 m
Strand length max at 1 bar
113 m
Strand length max at 2 bar
168 m
Strand length max at 3 bar
202 m
Strand length max at 4 bar
228 m
Type
Multibar C

Description

Drip hose for drip irrigation of plants, hedges, trees, etc. The advantage of drip irrigation is that water evaporation is minimal, and there is no water wastage by unnecessary areas such as paved surfaces being watered. This type, Multibar C, is also ideal for irrigation in areas with significant elevation differences, where very long pipelines, constant flow rates in every part of the system, and high delivery precision are required.

The drip hose is pressure-compensated, meaning that each dripper releases the same amount of water, regardless of pressure variations. If the drippers were not pressure-compensating, more water would flow out of the openings at the beginning of the hose than at the end of the hose.

The hose has an outer diameter of 16 mm and a roll length of 100 meters. A dripper is installed every 50 cm in the hose.
The drip hose is suitable for a water pressure of 0.5 to 4 bar. The maximum length of the hose is dependent on the pressure. If the maximum hose length is exceeded, water will not drip evenly from each dripper.

The water output is 1.6 liters per hour per dripper.

Due to the water supply, where the source is different from the water pipe, dirt can enter the drip hose. To prevent clogging of the drippers, it is recommended to install a filter with a 125-micron rating.

Features and benefits

  • Ideal for irrigation of multi-season crops.
  • The drip pressure compensating system is guaranteed by a silicone membrane that maintains a constant flow rate while varying the working pressure.
  • Suitable for sloped terrain and uneven landscapes.
  • The unique design of the dripper allows for efficient pressure compensation over a wide range.
  • Perfect dosing of fertilizers in every part of the system.
  • Drip hose with two emission holes in the opposite position (applies to all cylinders) that prevent the intake of impurities, for easy installation.
